Integrated Engineering Software Inc.

• Enhanced Model Tree for easy Physics assignments to the model
• 106+ newly added API functions, such as:
  Set transient values of the impressed electric field
  Set phasor values of the impressed electric field
  Assign congruent geometry to a permanent magnet
• Set transient values of the impressed electric field
• Set phasor values of the impressed electric field
• Assign congruent geometry to a permanent magnet
• Enhanced parametric setup dialog box for easy analysis
• New feature for designing complex windings in transformers
• New geometry creation commands
  Transformer analysis is one of the most widely used applications for our electromagnetic simulation software, and our customers depend on accurate, reliable results
  IES has helped the power and distribution, and manufacturing industries for decades, solving complex design challenges in an effort to make power systems and their components more efficient, affordable and environmentally friendly

Applications such as high voltage transmission require the analysis of flashover discharges
The insulators that support the power lines are associated with complicated conducting structures and corona rings
The simulation of a complete transmitting tower along with power lines – supported by the insulators – is fundamental for the estimation of the electric field levels at an arbitrary point on the insulators and the corona rings

INTEGRATED’s software programs are leading simulation tools to design Actuators
Our Actuator design software programs provides innovative proprietary Boundary Element Method (BEM) technology for the most accurate numerical field solutions to simulate the Actuators
Finite Element Method (FEM) analysis solver is also incorporated in programs to provide additional benefit

AMPERES™ is INTEGRATED’s powerful threedimensional magnetic field solver offering superior design capabilities in one fully integrated package
AMPERES™ greatly expands design potential and allows you to simulate and optimize electromagnetic components and systems before the manufacturing stage

FARADAY™, a 3D time-harmonic eddy current field solver from INTEGRATED Engineering Software gives you the advantage you need to meet this challenge head on
Using our innovative Boundary Element Method (BEM) and Finite Element Method (FEM) technologies, FARADAY™ is the only clear choice for applications requiring large open region analysis, exact modeling of boundaries and problems where dealing with small skin depths is critical

OERSTED™, a 2D/RS time-harmonic eddy current solver from INTEGRATED Engineering Software, delivers the power and performance needed to accomplish transient EM field solving
Using our innovative Boundary Element Method (BEM) technology with the Finite Element Method (FEM) solver, OERSTED™ distinguishes itself in magnetic design problems that require large open field analysis, exact modeling of boundaries and in applications where dealing with small skin depths are critical

ELECTRO™, the 2D/RS electric solver from INTEGRATED Engineering Software has set the standard for electric field design software
ELECTRO™ combines the advantages of both the Boundary Element Method (BEM) and Finite Element Method (FEM) field solvers

COULOMB™, a powerful 3D electric design and analysis software featuring our innovative Boundary Element Method (BEM) technology, well suited for applications where the design requires a large open field analysis and exact modeling of the boundaries

MAGNETO™, a fully integrated 2D/RS magnetic solver from Integrated Engineering Software puts you on the cutting edge of electromagnetic design
MAGNETO™ provides both Boundary Element Method (BEM) and Finite Element Method (FEM) solvers, so you can select the best analysis method for your application

LORENTZ™ suite of CAE programs provide sophisticated simulation and design tools customized for charged particle trajectory analysis in 2D/RS and 3D
The diverse applications of LORENTZ™ include studying the motion of particles in traps such as a Penning trap, or the paths of particles through optical components such as bending magnet and multiple focusing magnets, or the behavior of beams such as the dual grid ion gun
