Electrical calculation software for low and high voltage installations, from the Trace Software range

Electrical engineers sizing a low voltage or high voltage installation have to check cable sections, protection and short-circuit behavior against national and international standards. elec calc is the calculation package from Trace Software that does this work in real time. The company is French, has teams in several countries, and describes itself as long established in computer-aided engineering.
The core product sizes low voltage and high voltage networks and outdoor lighting installations, following a range of international standards. A graphical approach, summarized on the French site as drawing the schematic and having the calculation follow, lets a designer build the network and see results as it takes shape. Related tools in the range include an arc flash analysis option, a reader for sharing calculation files, a grid module, and QuickSchem for recording electrical data.
A separate offer brings the electrical calculation into the BIM workflow, which the company calls a unique Open BIM route for electrical installations. Projects can also be managed online with several participants working on the same elec calc files.
Trace Software also publishes the archelios suite for designing photovoltaic installations, forecasting yield and sizing systems connected to the public grid, with an online platform and a SketchUp link for modelling roofs in 3D. Other software on its site follows energy performance, supports feasibility studies for electrical and solar projects, and covers monitoring and data analysis, so that tools exist for each stage from master planning to design, execution and operation.
The company names critical facilities such as airports, data centers, hospitals, mining and nuclear plants, energy and solar work, infrastructure and construction, and process industries such as oil and gas and water treatment. It runs basic, advanced and custom training and technical webinars, offers technical support, custom developments and engineering services, and sells through resellers. Software can be purchased online.
Elec calc is a software package for calculating low voltage and high voltage electrical installations in real time. It is developed by Trace Software, a French company working in computer-aided engineering.
Trace Software serves engineering offices, installers and consultancies. Its material mentions sectors such as airports, data centres, hospitals, mining, energy, real estate, oil and gas, and water treatment.
Summary written by TrustList from the business's own published information, Nov 2026.
